Warranty length *

Our standard warranty is for a 2-year time period. An extended warranty is available up to a total of five years (2-year warranty plus 3 additional years). Extended warranties are calculated at 6% of the product cost, per year.

A 10GbE-connected spectrum analyzer perfect for mmWave analysis

The SM435C is a high-performance spectrum analyzer and monitoring receiver with a 10 Gigabit Ethernet SFP+ port, enabling the SM435C to communicate with a PC over long distances using a fiber optic cable. Designed for affordable remotely-located accurate RF data analysis up to 43.5 GHz, the SM435C is perfect for:

  • 5G mmWave monitoring & analysis
  • 24 GHz ISM frequency monitoring
  • Complete Ka band spectrum testing
  • Analysis of emerging & new high-frequency RF signals

Tuning from 100 kHz to 43.5 GHz, the SM435C has 160 MHz continuous streaming I/Q over 10GbE SFP+, 110 dB of dynamic range, 1THz/sec sweep speed at 30kHz RBW (using Nuttall windowing), and phase noise performance low enough to contribute less than 0.1% error to EVM measurements and rival even the most expensive spectrum analyzers on the market.

The smaller form factor of the SM435C allows it to inconspicuously fit in the corner of a test bench, or secured in a conveniently-sized enclosure.

This analyzer features:

  • An SFP+ port for fast, long-distance communication with a PC using an optic cable
  • 160 MHz continuous streaming I/Q over 10GbE SFP+
  • Device control and data transfer occurs via SFP+ connection, not USB
  • Tunes range of 100 kHz to 43.5 GHz
  • 20 MHz to 43.5 GHz sub-octave preselector
  • Sweeps at 1 THz/sec at 30 kHz RBW
  • 110 dB of dynamic range
  • Ultra-low phase noise
  • GPIO port for antenna switching

The SM435C includes all required software for operation. As with other Signal Hound devices, our Spike software provides the device controls, signal visualization display, and data export tools. Spike offers a variety of analysis modes and provides specific tools for EMC precompliance testing, interference hunting, and digital demodulation, among others.

For TSCM-specific applications, the SM435C is also compatible with the Kestrel and SCEPTRE software packages for the ultimate in affordable and powerful countermeasure solutions.

Reviews

There are no reviews yet.

Be the first to review “SM435C — 43.5 GHz Real-time Spectrum Analyzer with 10GbE”

Your email address will not be published. Required fields are marked *

This site uses Akismet to reduce spam. Learn how your comment data is processed.

Device dimensions

Version

SM435C — 43.5 GHz Real-time Spectrum Analyzer with 10GbE - Option 80, IF Output Option

Weight7.77 lbs (3.52 kg)
Dimensions10.2" x 7.2" x 2.15" (25.9 x 18.3 x 5.5 cm)
Version

SM435C — 43.5 GHz Real-time Spectrum Analyzer with 10GbE - Option 1 + Option 80, IF Output Option

Weight9.13 lbs. (4.14 kg)
Dimensions10.2” x 7.2” x 2.80” (25.9 x 18.3 x 7.11 cm)

Product-in-packaging dimensions

Version

SM435C — 43.5 GHz Real-time Spectrum Analyzer with 10GbE - Option 80, IF Output Option

Weight12.50 lbs. (5.67 kg)
Dimensions16.5" x 11" x 8.44" (41.9 x 27.9 x 21.44 cm)
Version

SM435C — 43.5 GHz Real-time Spectrum Analyzer with 10GbE - Option 1 + Option 80, IF Output Option

Weight13.66 lbs (6.20 kg)
Dimensions16.5" x 11" x 8.44" (41.9 x 27.9 x 21.44 cm)

Software and Drivers

Spike Software

  • Spectrum analysis software for all Signal Hound spectrum analyzers.
  • Installs the necessary USB drivers for the SM200 and SM435 devices.

Signal Hound Software Development Kit

  • Read API Docs
  • Includes programming interface for SM200 and SM435 devices.
  • Low level direct device control and measurements.
  • 64/32-bit Windows and 64-bit Linux operating systems.

Manuals

All manuals are included with the Spike software installer. For direct manual links see below.

SM200 and SM435 Product Manual

10GbE Network Configuration Guide

Firmware

Firmware updater for all models of the SM200 and SM435. You can see the current firmware version of your device in the Spike status bar.

Read the release_notes before updating the firmware on your device.

Firmware Updater (9/2/2022)

SM200 STEP File Downloads

3D model files (CAD) of the exterior of the SM200A, B, and C, in the Standard for the Exchange of Product Data (STEP) format. Perfect for those needing the physical specs of the SM200-series devices for system integration purposes.

SM200C STEP Files

SM200A/B STEP Files

SM435 STEP File Downloads

3D model files (CAD) of the exterior of the SM435B and SM435C, in the Standard for the Exchange of Product Data (STEP) format. Perfect for those needing the physical specs of the SM435-series devices for system integration purposes.

SM435B STEP Files

SM435C STEP Files
